Composite Repair Parts List - PTFE Fitted
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (cast iron uses SV302B or SVB307)
2.) The seat material is to match the water chamber material. In addition to this seat, (4) o-rings are needed. p/n V356T
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V003.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V005.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13 & 14)
P34-400DC ASY
13
2
Bearing Sleeve
P34-404
14
2
Main Shaft O-Ring
P34-403
15
2
Air Chamber
196.V006.157
16
2
Air Chamber Gasket
P79-109
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V006.000
22
8
O-ring
560.023.358
23
1
Muffler
530.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
PTFE Two Piece
PTFE Bonded
24
1
Main Shaft
P34-103
25
2
Diaphragm
V305TF
V305TX
26
2
Back-Up Diaphragm
V305TFB
N/A
27
2
Inner Diaphragm Plate
SV302TI
28
2
Outer Diaphragm Plate
SV302TO
29
2
Bumper Washer
P34-501
30
2
Back-Up Washer
V302E
31
4
Valve Seat (See Below Material Chart)
V356xx
32
4
Valve Ball
V355TF
Wet End Assembly
Item #
Qty.
Description
Part Number
Aluminum
Cast Iron
Stainless Steel
Hastelloy
33
2
Water Chamber
V350
WV350
SV350
HV350
34
2
Large Clamp Assembly
V311
SV311
35
1
Discharge Manifold
V351
WV351
SV351
HV351
36
1
Suction Manifold (Footed Option)
V352F
WV352F
SV352F
HV352F
37
1
Suction Manifold (Screen Mount Option)
V352
N/A
N/A
N/A
38
1
Screen (Screen Mount Only)
V353
N/A
N/A
N/A
39
3
Bolt (Screen Mount Only)
V238A
N/A
N/A
N/A
40
1
Hook Up Cover (Screen Mount Only)
V357
N/A
N/A
N/A
41
4
Small Clamp Assembly
V354
SV354
42
2
Diaphragm Seal Tape Kit (Not Pictured)
720.V006.000
Elastomer Material Specifications
Material
Seat P/N
PTFE
V356TF
Aluminum
V356A (See Note 2 Below)
Stainless Steel
SV356 (See Note 2 Below)
Hastelloy
HV356 (See Note 2 Below)
3: EXP
