Model specific – Versa-Matic 3 Elima-Matic Clamped Metallic - ATEX (E3) User Manual
Page 15
e3mdlCsmATEXC-rev0514
Model E3 Metallic Clamped •
12
www
.
versamatic
.
com
Composite Repair Parts List - Elastomeric and TPE Fitted
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (cast iron uses SV302B or SVB307)
2.) The seat material is to match the water chamber material. In addition to this seat, (4) O-Rings are needed. p/n V356T
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V003.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V005.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13 & 14)
P34-400DC ASY
13
2
Bearing Sleeve
P34-404
14
2
Main Shaft O-Ring
P34-403
15
2
Air Chamber
196.V006.157
16
2
Air Chamber Gasket
P79-109
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V006.000
22
8
O-ring
560.023.358
23
1
Muffler
530.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
Versa-Rugged
Versa-Dome
24
1
Main Shaft
P34-103
25
2
Diaphragm (See Below Material Chart)
V305xx
V306xx
26
2
Outer Diaphragm Plate (See Note 1 Below)
V302BDC, SV302B
VB307, SVB307
27
2
Inner Diaphragm Plate
V302CDC
V307B
28
12
Bolt
V302G
N/A
29
12
Washer
V302GA
N/A
30
2
Bumper Washer
P34-501
31
2
Back-Up Washer
V302E
32
4
Valve Seat (See Below Material Chart)
V356xx
33
4
Valve Ball (See Below Material Chart)
V355xx
Wet End Assembly
Item #
Qty.
Description
Part Number
Aluminum
Cast Iron
Stainless Steel
Hastelloy
34
2
Water Chamber
V350
WV350
SV350
HV350
35
2
Large Clamp Assembly
V311
SV311
36
1
Discharge Manifold
V351
WV351
SV351
HV351
37
1
Suction Manifold (Footed Option)
V352F
WV352F
SV352F
HV352F
38
1
Suction Manifold (Screen Mount Option)
V352
N/A
N/A
N/A
39
1
Screen (Screen Mount Only)
V353
N/A
N/A
N/A
40
3
Bolt (Screen Mount Only)
V238A
N/A
N/A
N/A
41
1
Hook Up Cover (Screen Mount Only)
V357
N/A
N/A
N/A
42
4
Small Clamp Assembly
V354
SV354
Elastomer Material Specifications
Material
Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
"Ball P/N"
Seat P/N
Neoprene
V305N
V306N
V355N
V356N
Nitrile
V305BN
V306BN
V355BN
V356BN
FKM
V305VT
V306VT
V355VT
V356VT
EPDM
V305ND
V306ND
V355ND
V356ND
PTFE
N/A
N/A
V355TF
V356TF
Santoprene
V305TPEXL
N/A
V355TPEXL
V356TPEXL
Hytrel
V305TPEFG
N/A
V355TPEFG
V356TPEFG
Geolast
V305G
N/A
N/A
V356G
Aluminum
N/A
N/A
N/A
V356A (See Note 2 Below)
Carbon Steel
N/A
N/A
N/A
V356CS (See Note 2 Below)
Stainless Steel
N/A
N/A
N/A
SV356 (See Note 2 Below)
Hastelloy
N/A
N/A
N/A
HV356 (See Note 2 Below)
MODEL SPECIFIC
3: EXP
VIEW
