Dimensional drawings, E2 metallic bolted, Warren rupp, inc – Versa-Matic 2 Elima-Matic Bolted Metallic – ATEX (E2) User Manual
Page 9: Pump specs, Model e2 metallic bolted, Dimensions in inches (mm dimensions in brackets)
e2mdlCsmATEXMB-rev0614
www
.
versamatic
.
com
Model E2 Metallic Bolted •
6
Dimensional Drawings
E2 Metallic Bolted
Dimensionally Interchangeable with Wilden Clamped Pump
Dimensions in inches (mm dimensions in brackets)
The dimensions on this drawing are for reference only. A certified drawing can be requested if physical dimensions are needed.
DO NOT SCALE DRAWING
DIMENSIONS ARE INCHES
SURFACE FINSH
1/2
ANGULAR
.010
.005
.XX
.XXX
UNLESS OTHERWISE
SPECIFIED
TOLERANCES
63
MATERIAL
EST WT:
3
lbs
in
VOLUME:
STAINLESS STEEL
17.72
450.04
24.74
628.40
19.85
504.16
.38
9.53
9.82
249.30
2.50
63.50
1/2" NPT
AIR INLET
1" NPT
EXHAUST PORT
2" NPT/BSP TAPERED
DISCHARGE PORT
2" NPT/BSP TAPERED
SUCTION PORT
10.10
256.54
10.10
256.54
9.10
231.14
12.40
314.96
R.30
7.62
2.30
58.42
2.40
60.96
26.24
666.50
12.00
304.80
2.40
60.83
NOTES:
1. THE DIMENSIONS ON THIS DRAWING ARE FOR REFERENCE ONLY. A
CERTIFIED DRAWING CAN BE REQUESTED IF PHYSICAL DIMENSIONS ARE NEEDED
B
CHANGED DIMENSION 1.72 TO 2.50 ON SUCTION MANIFOLD
JLL
4/29/13
A
INITIAL RELEASE
JLL
10/27/12
REV
REVISION
CHG
DATE
APP
DATE
ECN
SHEET
C
6
7
8
A
8
7
6
5
4
3
2
1
D
B
D
C
B
A
1 1
of
E2SAxxxx9C-DW
E2
B
E2 VM DROP IN PUMP
PART NUMBER
E2SAxxxx9C-DW
of 1
1
SHEET
REV
DRAWING NUMBER
DESCRIPTION
PUMP REFERENCE
PROJECT
MADE FROM
THIS IS A PROPRIETARY DOCUMENT. DO NOT REPRODUCE OR DISCLOSE WITHOUT THE
EXPRESS WRITTEN PERMISSION OF WARREN RUPP, INC
N/A
WARREN RUPP, INC
DO NOT SCALE DRAWING
