Versa-Matic 2 Elima-Matic Bolted Metallic – ATEX (E2) - Manual (Page 7)

e2mdlCsmATEXMB-rev0614
www
.
versamatic
.
com Model E2 Metallic Bolted •
4
E2 Metallic Bolted - Optional Horizontal Discharge
Dimensionally Interchangeable for Versa-Matic and Wilden
Dimensions in inches (mm dimensions in brackets)
The dimensions on this drawing are for reference only. A certified drawing can be requested if physical dimensions are needed.
Dimensional Drawings
3.39
10.03
20.06
25.01
17.72
2" 150# ANSI / DIN
DISCHARGE FLANGE
2" 150# ANSI / DIN
SUCTION FLANGE
1/2" NPT
AIR INLET
1" NPT
AIR EXHAUST
28.01
2.70
.38
12.03
R.28
11.00
11.50
10.00
13.50
2.00
BOTTOM VIEW
3.39
10.03
20.06
25.01
17.72
2" 150# ANSI / DIN
DISCHARGE FLANGE
2" 150# ANSI / DIN
SUCTION FLANGE
1/2" NPT
AIR INLET
1" NPT
AIR EXHAUST
28.01
2.70
.38
12.03
R.28
11.00
11.50
10.00
13.50
2.00
BOTTOM VIEW
Model Specific
1: PUMP
SPECS
