Composite repair parts list, Model specific – Versa-Matic 2 Elima-Matic Flap Valve – ATEX (E2) User Manual
Page 12
e2mdlCsmATEXFV-rev0514
www
.
versamatic
.
com
9
• Model E2 Metallic Flap Valve
Composite Repair Parts List
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V002.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V006.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13 & 14)
P24-400DC ASY
13
2
Bearing Sleeve
P31-403
14
2
Main Shaft O-Ring
P24-403
15
2
Air Chamber
196.V002.157
16
2
Air Chamber Gasket
360.V001.360
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V002.000
22
8
O-ring
560.023.358
23
1
Muffler
560.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
Versa-Rugged
Versa-Dome
24
1
Main Shaft
P24-103
25
2
Diaphragm (See Below Material Chart)
V224xx
V225xx
26
2
O-ring
V221D
N/A
27
2
Inner Diaphragm Plate
V221B
V226B
28
2
Bumper Washer
P24-501
29
2
Outer Diaphragm Plate
VB221
VB226
30
4
Valve Seat (See Below Material Chart)
V240xx
31
4
Flapper Seat Seal (See Below Material Chart)
FV26xx
32
4
Flapper Seat
FV28
33
4
Flapper (See Below Material Chart)
FV24xx
34
4
PTFE Pad
FV25TF
35
4
Flapper Valve Pad (See Below Material Chart)
FV25xx
36
4
Flap Retainer
FV27
37
8
Bolt
FV27AS
Wet End Assembly
Item #
Qty.
Description
Part Number
38
2
Water Chamber
FV235
39
2
Large Clamp Assembly
V230
40
2
Discharge Manifold Tee
FV236
Discharge Manifold Tee (BSP Option)
FV236BSP
41
1
Discharge Manifold Elbow
FV236E
42
2
Mounting Bracket
FV237MB
43
1
Suction Manifold Tee
FV237
Suction Manifold Tee (BSP Option)
FV237BSP
44
2
Suction Manifold Elbow
FV237E
45
16
Bolt
FV230C
46
16
Washer
V242
47
16
Nut
V302GA
48
4
Small Clamp Assembly
V354C
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
Seat P/N
Flapper Valve
Pad P/N
"Flap P/N"
Flapper Seat
Seal P/N
Neoprene
V224N
V225N
V240N
FV25N
FV24N
FV26N
Nitrile
V224BN
V225BN
V240BN
FV25BN
FV24BN
FV26BN
FKM
V224VT
V225VT
V240VT
FV25VT
FV24VT
FV26VT
EPDM
V224ND
V225ND
V240ND
FV25ND
FV24ND
FV26ND
Santoprene
V224TPEXL
V225TPEXL
V240TPEXL
N/A
N/A
N/A
Hytrel
V224TPEFG
V225TPEFG
V240TPEFG
N/A
N/A
N/A
Geolast
V224G
N/A
V240G
N/A
N/A
N/A
MODEL SPECIFIC
3: EXP
VIEW
