Model E2 Aluminum Bolted •
12
Composite Repair Parts List - PTFE Fitted
Notes:
1.) These (4) o-rings are only used with metallic fitted seats.
2.) This metallic seat requires (4) V240T O-Rings.
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V002.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V006.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13 & 14)
P24-400DC ASY
13
2
Bearing Sleeve
P31-403
14
2
Main Shaft O-Ring
P24-403
15
2
Air Chamber
196.V004.156
16
2
Air Chamber Gasket
360.V001.465
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V002.000
22
8
O-ring
560.023.358
23
1
Muffler
530.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
PTFE Two Piece
Fusion
24
1
Main Shaft
P24-102
P24-103F
25
2
Shaft Stud
V221F
N/A
26
2
Diaphragm
V224TF-FB
V224F
27
2
Back Up Diaphragm
V224TFB
N/A
28
2
Inner Diaphragm Plate
V221TI
N/A
29
2
Bumper Washer
P24-501
30
2
Outer Diaphragm Plate
V221TO
N/A
31
4
Valve Seat (See Material Chart Below)
V240xx
32
4
Valve Seat O-Ring
V240T (See Note 1)
33
4
Valve Ball
V241TF
Wet End Assembly
Item #
Qty.
Description
Part Number
34
2
Water Chamber
V235FB
35
16
Water Chamber Bolt
170.020.330
36
1
Discharge Manifold
V236FB
Discharge Manifold (BSP Option)
V236FBBSP
Discharge Drop in Manifold
518.V006.156
Discharge Drop in Manifold (BSP)
518.V006.156 E
WD Discharge Drop in Manifold
518.V006.156 W
WD Discharge Drop in Manifold (BSP)
518.V006.156 E
37
1
Suction Manifold
V237FB
Suction Manifold (BSP Option)
V237FBBSP
Suction Drop in Manifold
518.V007.156
Suction Drop in Manifold (BSP)
518.V007.156 E
38
12
Manifold Bolt
V251D
39
28
Nut
V354C
40
28
Washer
V302GA
Material Specifications
Material
Seat P/N
Aluminum
V240A (See Note 2 Below)
Stainless Steel
SV240 (See Note 2 Below)
3: EXP
VIEW
