Versa-Matic 2 Elima-Matic Bolted Aluminum – ATEX (E2) - Manual (Page 13)

e2mdlCsmATEXAB-rev0514
www
.
versamatic
.
com Model E2 Aluminum Bolted •
10
Composite Repair Parts List - Elastomeric and TPE Fitted
Notes:
1.) The metallic seat material is to match the water chamber material. In addition to this seat, (4) o-rings are needed. (Ref Note 2)
2.) These (4) o-rings are only used with metallic fitted seats.
Air Valve Assembly
Item # Qty. Description Part Number
1 1 Valve Body Assembly (includes items 2-11) 031.V002.156
2 1 Valve Body 095.V001.156
3 1 Valve Body Gasket P24-202
4 1 Valve Sleeve 755.V006.148
5 6 O-ring 560.206.360
6 1 Valve Spool Assembly (Includes items 7) 775.V001.000
7 6 Glyde Ring Assembly P34-204F
8 1 Air Valve Screen P24-210
9 2 End Cap Gasket P24-205
10 2 End Cap P34-300
11 13 Mounting Screws (8 included on item 1) S1001
Center Section Assembly
Item # Qty. Description Part Number
12 1 Center Block Assembly (Includes item 13 & 14) P24-400DC ASY
13 2 Bearing sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 2 Air Chamber 196.V004.156
16 2 Air Chamber Gasket P79-109
17 8 Bolt P24-110
18 1 Pilot Sleeve Assembly (include item 19) 755.V002.000
19 6 O-ring 560.101.358
20 1 Retaining Ring 675.037.080
21 1 Pilot Spool Assembly (Includes item 22) 775.V002.000
22 8 O-ring 560.023.358
23 1 Muffler 530.033.000
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Versa-Rugged Versa-Dome
24 1 Main Shaft P24-103
25 2 Diaphragm (See Below Material Chart) V224xx V225xx
26 2 O-ring V221D N/A
27 2 Inner Diaphragm Plate V221B V226B
28 2 Bumper Washer P24-501
29 2 Outer Diaphragm Plate VB221 VB226
30 4 Valve Seat (See Below Material Chart) V240xx
31 4 Valve Seat O-Ring (See Below Material Chart) (See Note 2)
32 4 Valve Ball (See Below Material Chart) V241xx
Wet End Assembly
Item # Qty. Description Part Number
33 2 Water Chamber V235FB
34 16 Water Chamber Bolt 170.020.330
35 1
Discharge Manifold V236FB
Discharge Manifold (BSP Option) V236FBBSP
Discharge Drop in Manifold 518.V006.156
Discharge Drop in Manifold (BSP) 518.V006.156 E
WD Discharge Drop in Manifold 518.V006.156 W
WD Discharge Drop in Manifold (BSP) 518.V006.156 WE
36 1
Suction Manifold V237FB
Suction Manifold (BSP Option) V237FBBSP
Suction Drop in Manifold 518.V007.156
Suction Drop in Manifold (BSP) 518.V007.156 E
37 12 Manifold Bolt V251D
38 28 Nut V354C
39 28 Washer V302GA
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
"Ball P/N" Seat P/N Seat O-Ring
Neoprene V224N V225N V241N V240N N/A
Nitrile V224BN V225BN V241BN V240BN N/A
FKM V224VT V225VT V241VT V240VT N/A
EPDM V224ND V225ND V241ND V240ND N/A
PTFE N/A N/A V241TF V240TF V240T
Santoprene V224TPEXL V225TPEXL V241TPEXL V240TPEXL N/A
Hytrel V224TPEFG V225TPEFG V241TPEFG V240TPEFG N/A
Geolast V224G N/A V241G V240G N/A
Aluminum N/A N/A N/A
V240A
(See Note 1 Below)
N/A
