Composite repair Parts list
Air Valve Assembly
Item # Qty. Description
Part Number
Aluminum Nickel Plated PTFE Coated
1 - Valve Body Assembly (includes items 2-7) P31-200 P31-200-NP P31-200-TC
2 1 Valve Body P31-201 P31-201NP P31-201TC
3 2 End Cap P50-300 P50-300NP P50-300TC
4 2 End Cap Gasket P50-110
5 1 Valve Body Gasket P31-202
6 1 Valve Spool P50-104
7 3 Glyde Ring Assembly P50-104C
8 12 Mounting Screws S100A
Center Section Assembly
Item # Qty. Description
Part Number
Aluminum Nickel Plated PTFE Coated
9 1 Center Block Assembly (Includes item 13 & 14) P31-400DC ASY P31-401NP P31-401TC
10 2 Air Chamber E401 E401NP E401TC
11 2 Air Chamber Gasket P31-109
12 8 Bolt P31-404
13 2 Bearing Sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 1 Pilot Shaft P50-112
16 5 Pilot Spacer P24-106P
17 6 Pilot O-Ring P24-107
18 2 Pilot Ring P50-119
19 2 Pilot Retainer P50-109
20 2 Screw S1001
21 2 Stop Nut P24-108
22 1 Muffler VTM-6
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Polypropylene PVDF
Versa-Rugged Fusion Versa-Rugged Fusion
23 2 Diaphragm (See Below Material Chart) V163xx V163F V163xx V163F
24 2 Inner Diaphragm Plate (See Note 2 Below)
V161C, V161CNP,
V161CTC
N/A
V161C, V161CNP,
V161CTC
N/A
25 2 Outer Diaphragm Plate (See Note 1 Below) PE413 N/A KE413 N/A
26 1 Main Shaft P31-103
27 4 Valve Seat (See Below Material Chart) E408xx
28 8 Seat O-ring (See note 3 Below) E412TES
29 4 Valve Ball (See Below Material Chart) V171xx
30 4 Manifold Tee O-Ring E413xx
Wet End Assembly
Item # Qty. Description
Part Number
Polypropylene PVDF
31 2 Water Chamber PE404 KE404
32 2 Manifold Tee PE411 KE411
33 2 Discharge Elbow PE409 KE409
34 2 Suction Elbow PE409F KE409F
35 8 Detent Pin E417
36 24 Bolt SV189D
37 32 Washer SV189C
38 12 Nut SV185B
39 8 Water Chamber Bolt (Short) SV187A
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N "Ball P/N" Seat P/N "Seat O-Ring P/N"
"Manifold Tee
O-Ring P/N"
Neoprene V163N V171N E408N N/A N/A
Nitrile V163BN V171BN E408BN N/A E413BN
FKM V163VT V171VT E408VT N/A E413VT
EPDM V163ND V171ND E408ND N/A E413ND
PTFE N/A V171TF N/A E412TES E413TES
Santoprene V163TPEXL V171TPEXL E408XL N/A E413XL
Hytrel V163TPEFG V171TPEFG E408FG N/A N/A
Geolast V163G V171G N/A N/A N/A
Polypropylene N/A N/A E408P (See Note 3) N/A N/A
PVDF N/A N/A E408K (See Note 3) N/A N/A
Notes:
1.) The outer diaphragm plate material is to match the water chamber material
2.) The inner diaphragm plate material is to match the air chamber material
3.) These o-ring are only used with valve seats
4.) TC=PTFE Coated, NP=Nickel Plated
