• Model E1 Metallic Bolted
Composite Repair Parts List
Note: The outer diaphragm plate material is to match the water chamber material
Air Valve Assembly
Item #
Qty.
Description
Part Number
-
1
Air Valve Assembly (includes items 1-10)
031.V006.156
1
1
Valve Body
P98-102UB
2
1
Valve Spool Assembly (Includes items 3&4)
P98-105UB ASY
3
1
Large Valve Spool U-Cup
P98-105B
4
1
Small Valve Spool U-Cup
P98-105A
5
2
Metal End Cap
P98-300
6
2
End Cap Gasket (for metal)
P98-110
7
1
CT Air Diverter
P98-105CT
8
1
Air Diverter Plate
P98-106
9
1
Air Valve Gasket
P98-111UB
10
12
Mounting Screws (8 included on Air Valve Assembly)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
Aluminum
PTFE Coated
Nickel Plated
11
1
Center Section
114.V001.157
114.V001.309
114.V001.332
12
1
Pilot Spool ASY (includes item 13)
775.V005.000
13
7
Pilot Spool O-Rings
560.023.358
14
1
Pilot Valve Sleeve ASY (includes item 15)
755.V004.000
15
6
Pilot Valve Sleeve O-Rings
560.101.358
16
2
Shaft/Pilot Retainer
670.V002.554
10
4
Retainer Screw
S1001
17
1
Muffler
VTM-4A
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
TPE/RUBBER
PTFE 2-Piece
PTFE Fusion
18
2
Main Shaft O-Ring
P50-403
19
1
Main Shaft
685.V001.120
P50-108
20
2
Diaphragm
"V183xx-1
(See Below Material Chart)"
V183TF-1
V183F
21
2
Back-Up Diaphragm
N/A
V183TB
N/A
22
2
Inner Diaphragm Plate
V181C
V181C
N/A
23
2
Outer Diaphragm Plate (See Note 1 Below)
V81B, SV181B ASY,
HV181TO
SV181TO, HV181TO
N/A
24
4
Valve Seat O-Ring
"V90xx
(See Below Material Chart)"
SV190TF
25
4
Valve Ball
"V191xx
(See Below Material Chart)"
V191TF
Wet End Assembly
Item #
Qty.
Description
Part Number
Aluminum
Stainless Steel
Hastelloy
26
4
Valve Seat
V90A
SV190
HV190
27
2
Water Chamber
V85
SV185
HV185
28
16
Water Chamber Bolt
V189A
SV189D
29
16
Water Chamber Washer
V189C
SV189C
30
16
Water Chamber Nut
V185B
SV185B
31
1
Discharge Manifold
V86
SV186
HV186
Discharge Manifold (BSP Option)
V86BSP
SV186BSP
HV186BSP
32
1
Suction Manifold
V87
SV187
HV187
Suction Manifold (BSP Option)
V87BSP
SV187BSP
HV187BSP
33
8
Manifold Bolt
V187A
SV189D
29
8
Manifold Washer
V189C
SV189C
30
8
Manifold Nut
V185B
SV185B
Elastomer Material Specifications
Material
Diaphragm P/N
Valve Ball P/N
O-Ring P/N
Neoprene
V183N-1
V191N
N/A
Buna Nitrile
V183BN-1
V191BN
V90BN
Viton
V183VT-1
V191VT
V90VT
Nordel
V183ND-1
V191ND
V90ND
Santoprene
V183TPEXL-1
V191TPEXL
V190XL
Hytrel
V183TPEFG
V191TPEFG
N/A
Geolast
V183G
V191G
N/A
Acetal
N/A
V191A
N/A
Stainless Steel
N/A
V191SS
N/A
