Versa-Matic 2 Ultra-Matic Metallic Flap Valve - Manual (Page 11)

u2msmFV-rev0314
Model U2 Metallic Flap Valve •
8
www
.
versamatic
.
com
Composite repair Parts list
* Add "BSP" for BSP threads.
AIR VALVE ASSEMBLY
Item Description Qty Standard: Polypropylene
Air Valve Assembly 1 E200
(Includes items 1-10)
1
Valve Body 1 E200A
2 Valve Spool Assembly 1 E200B ASY (Includes U-Cups)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap Assembly 2 E500D ASY (Includes O-Rings)
5 End Cap Staple 2 E500F
6 Staple Retainer 2 E200L
7 Air Diverter 1 E200G
8 Valve Insert 1 E200H
9 Valve Gasket 1 E200J
10 Valve Cap Screw 4 P24-209
AIR END ASSEMBLY
Item Description Qty Standard: Polypropylene / Aluminum
15 Center Block 1 E210
16 Air Chamber Gasket 2 E212
17 Air Chamber 2 E211
18 Air Chamber Bolt 12 V302G
19 Air Chamber Nut 2 V354C
20 Air Chamber Washer 12 V302GA
21 Bushing 2 E201MB
22 Pilot Shaft 1 E203A
23 Pilot Shaft Spacer 5 P24-106P
24 Pilot Shaft O-Ring 6 P24-107
25 Stop Nut 2 P24-108
26 Shaft Retainer – Left 1 E201B-L ASY (Includes O-Rings)
27 Shaft Retainer – Right (not shown) 1 E201B-R ASY (Includes O-Rings)
28 Shaft Retainer O-Ring 2 E201B-5
29 Shaft Retainer Screw 8 10-050
30 Exhaust Valve 2 E202 ASY
31 Exhaust Sleeve O-Ring 2 560.013.360
32 Retainer Plate Seal 2 P34-403
33 Muffler Plate 1 E201H
34 Muffler Plate Gasket 1 E200J-1
35 Muffler Plate Cap Screw 4 E201G
36 Muffler Elbow 1 PE201N
37 Muffler 1 V20AEM
38 Air Chamber O-Ring 2 P24-107
DIAPHRAGM ASSEMBLY
Item Description Qty Rugged Dome Teflon Bonded Teflon 2-Piece
40 Main Shaft 1 P24-103 P24-103 P24-102 P24-102
41 Diaphragm Shaft Stud 2 N/A N/A V221F V221F
42 Inner Diaphragm Plate 2 V221B V226B V221TI V221TI
43 Outer Diaphragm Plate 2 VB221 VB226 V221TO V221TO
44 Diaphragm O-Ring 2 V221D N/A N/A N/A
V224BN V224N V225BN V225N
45 Diaphragm 2 V224TPEXL V224VT V225TPEXL V225VT V224TX V224TF
V224ND V224TPEFG V225ND V225TPEFG
46 Back-up Diaphragm 2 N/A N/A N/A V224TFB
WET END ASSEMBLY
Item Description Qty Standard: Aluminum
50 Water Chamber 2 V235
51 Large Clamp Bolt 4 V230C
52 Large Clamp Nut 20 V230D
53 Large Clamp Assembly 2 V230
54 Valve Seat 4 V240BN V240N V240ND V240TPEFG V240TF V240VT V240TPEXL V240A SV240 HV240 WV240
55 Valve Seat O-Ring (Not Shown) 4 V240T (Use with V240A SV240 HV240 WV240 only)
56 Seal Ring 4 FV26BN FV26N FV26ND V246VT
57 Seal Plate 4 FV28
58 Flap 4 FV24BN FV24N FV24ND FV24VT
59 PTFE Pad 4 FV25TF
60 Pad 4 FV25BN FV24N FV25ND FV25VT
61 Flap Retainer 4 FV27
62 Flap Retainer Bolt 8 FV27AS
63 Discharge Elbow 2 FV236E
64 Discharge Manifold 1 FV236*
65 Suction Manifold 1 FV237*
66 Suction Elbow 2 FV237-E
67 Small Clamp Bolt 8 V239B
68 Small Clamp Nut 8 V239C
69 Small Clamp Assembly 4 V239
70 Manifold Washer 12 V302GA
71 Manifold Bolt 16 FV230C
72 Manifold Nut 16 V230D
3: EXP
VIEW
