Versa-Matic 2 Ultra-Matic Metallic Food Processing - Manual (Page 12)

u2msmFP-rev0314
9
• Model U2 Metallic Food Processing www
.
versamatic
.
com
Composite repair Parts drawing - Exploded View
See Detail C:
Exhaust Valves
See Detail B:
Pilot Shaft
Shown with Versa-Rugged Diaphragms
See Detail D for Versa-Dome Diaphragms
See Detail E for PTFE Bonded Diaphragms
See Detail F for PTFE 2-Piece Diaphragms
See Detail A:
Air Valve
52
53
57
60 61
42 18
45 44
59
51
43
50
40 32
29
26
17
16 15
34
38
20
19
33
35
36
37
58
56
54
Small Clamp Bolts 50 in-lbs (5.6 N-m)
Large Clamp Bolts 20ft-lbs (27 N-m)
Diaphragm Plates — Rubber 65 ft-lbs (88 N-m)
Diaphragm Plates — PTFE 65 ft-lbs (88 N-m)
Air Valve Cap Screws 25 in-lbs (2.8 N-m)
Muffler Plate Cap Screws 30 in-lbs (3.4 N-m)
Air Chamber Bolts 20 ft-lbs (27 N-m)
Torque Settings
General Model Specific
3: EXP
VIEW
