Versa-Matic 2 Ultra-Matic Metallic Food Processing - Manual (Page 11)

u2msmFP-rev0314
Model U2 Metallic Food Processing •
8
www
.
versamatic
.
com
Composite repair Parts list
* Add "BSP" for BSP threads.
AIR VALVE ASSEMBLY
Item Description Qty Standard: Polypropylene
Air Valve Assembly 1 E200
(Includes items 1-10)
1 Valve Body
1 E200A
2 Valve Spool Assembly 1 E200B ASY (Includes U-Cups)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap Assembly 2 E500D ASY (Includes O-Rings)
5 End Cap Staple 2 E500F
6 Staple Retainer 2 E200L
7 Air Diverter 1 E200G
8 Valve Insert 1 E200H
9 Valve Gasket 1 E200J
10 Valve Cap Screw 4 P24-209
AIR END ASSEMBLY
Item Description Qty Standard: Polypropylene / Nickel Plated Option 1: Polypropylene / Stainless
15 Center Block 1 E210 E210
16 Air Chamber Gasket 2 E212 E212
17 Air Chamber 2 E211NP SE211
18 Air Chamber Bolt 12 V3181F V181F
19 Air Chamber Nut 2 V354C SV354C
20 Air Chamber Washer 12 V302GA SV302GA
21 Bushing 2 E201MB E201MB
22 Pilot Shaft 1 E203A E203A
23 Pilot Shaft Spacer 5 P24-106P P24-106P
24 Pilot Shaft O-Ring 6 P24-107 P24-107
25 Stop Nut 2 P24-108 P24-108
26 Shaft Retainer – Left 1 E201B-L ASY (Includes O-Rings) E201B-L ASY (Includes O-Rings)
27 Shaft Retainer – Right (not shown) 1 E201B-R ASY (Includes O-Rings) E201B-R ASY (Includes O-Rings)
28 Shaft Retainer O-Ring 2 E201B-5 E201B-5
29 Shaft Retainer Screw 8 10-050 10-050
30 Exhaust Valve 2 E202 ASY E202 ASY
31 Exhaust Sleeve O-Ring 2 560.013.360 560.013.360
32 Retainer Plate Seal 2 P34-403 P34-403
33 Muffler Plate 1 E201H E201H
34 Muffler Plate Gasket 1 E200J-1 E200J-1
35 Muffler Plate Cap Screw 4 E201G E201G
36 Muffler Elbow 1 PE201N PE201N
37 Muffler 1 V20AEM V20AEM
38 Air Chamber O-Ring 2 P24-107 P24-107
DIAPHRAGM ASSEMBLY
Item Description Qty Versa-Rugged Versa-Dome Teflon Bonded Teflon 2-Piece
40 Main Shaft 1 P24-103 P24-103 P24-102 P24-102
41 Diaphragm Shaft Stud 2 N/A N/A V221F V221F
42 Inner Diaphragm Plate 2 V221BNP V226BNP V221TINP V221TINP
43 Outer Diaphragm Plate 2 SVB221FG SVB226FG SV221TOFG SV221TOFG
44 Diaphragm O-ring 2 V221D N/A N/A N/A
45 Diaphragm 2 V224TPEFG V225TPEFG V224TX V224TF
46 Back-up Diaphragm 2 N/A N/A N/A V224TFB
46 Back-up Diaphragm 2 N/A N/A N/A V224TFB
WET END ASSEMBLY
Item Description Qty Standard: Electro polished Stainless Steel
50 Water Chamber 2 SV235FG
51 Large Clamp Bolt 4 SV230C
52 Large Clamp Wing Nut 4 FG30D
53 Large Clamp Assembly 2 SV230
54 Valve Seat 4 V240TPEFG SV240 (Use with V240T O-ring)
55 Valve Seat O-Ring (not shown) 4 V240T (Use with SV240 only)
56 Valve Ball 4 V241TF V241TPEFG V240SS
57 Discharge Manifold 1 SV236FG
58 Inlet Manifold 1 SV237FFG
59 Small Clamp Bolt 8 SV239B
60 Small Clamp Win Nut 8 FG39C
61 Small Clamp Assembly 8 SV239
3: EXP
VIEW
