• Model U2 Non-Metallic Bolted www
.
versamatic
.
com
Composite repair Parts list
* Add "BSP" for BSP threads.
AIR VALVE ASSEMBLY
Item Description Qty Standard: Polypropylene
Air Valve Assembly 1 E200
(Includes items 1-10)
1
Valve Body 1 E200A
2 Valve Spool Assembly 1 E200B ASY (Includes U-Cups)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap Assembly 2 E500D ASY (Includes O-Rings)
5 End Cap Staple 2 E500F
6 Staple Retainer 2 E200L
7 Air Diverter 1 E200G
8 Valve Insert 1 E200H
9 Valve Gasket 1 E200J
10 Valve Cap Screw 4 P24-209
AIR END ASSEMBLY
Item Description Qty Standard: Polypropylene
15 Center Section 1 E201A
16 Bushing 2 E201MB
17 Pilot Shaft 1 E203A
18 Pilot Shaft Spacer 5 P24-106P
19 Pilot Shaft O-Ring 6 P24-107
20 Stop Nut 2 P24-108
21 Shaft Retainer – Left 1 E201B-L ASY (Includes O-Rings)
22 Shaft Retainer – Right (not shown) 1 E201B-R ASY (Includes O-Rings)
23 Exhaust Sleeve O-Ring 2 560.013.360
24 Shaft Retainer Screw 2 10-050
25 Exhaust Valve 2 E202 ASY
26 Shaft Retainer O-Ring 2 E201B-5
27 Retainer Plate Seal 2 P34-403
28 Muffler Plate 1 E201H
29 Muffler Plate Gasket 1 E200J-1
30 Muffler Plate Cap Screw 4 E201G
31 Muffler Elbow 1 PE201N
32 Muffler 1 V20AEM
DIAPHRAGM ASSEMBLY
Item Description Qty DOME PTFE Bonded PTFE 2-Piece
40 Main Shaft 1 P24-103 P24-102 P24-102
41 Diaphragm Shaft Stud 2 N/A V221F V221F
42 Inner Diaphragm Plate 2 V226B SV226B V221T SV221TI V221TI SV221TI
V226BTC 226BN V221TITC V221TINP V221TITC V221TINP
43 Outer Diaphragm Plate 2 PV226B KV226B PV221TO KV221TO PV221TO KV221TO
V227BN V227N
45 Diaphragm 2 V227ND V227VT V227TX V227TF
V227TPEXL V227TPEFG
46 Back-up Diaphragm 2 N/A N/A V227TFB
WET END ASSEMBLY
Item Description Qty Standard: Polypropylene Option 1: Kynar
50 Water Chamber 2 PV235 KV235
51 Water Chamber Bolt (long) 8 E235A E235A
52 Water Chamber Bolt (short) 12 SV186A SV186A
53 Water Chamber Washer 20 SV250C SV250C
54 Valve Seat 4 PV240 KV240
55 Valve Seat O-Ring 8 V258BN V258ND V258TES V258TEV V258VT V258XL
56 Valve Ball 4 V241BN V241N V241ND V241P V241TF V241TPEXL V241TPEFG V241VT
Port Option 1: Side Port
57 Discharge Manifold 1 PV236 KV236
58 Inlet Manifold 1 PV237 KV237
59 Manifold Bolt 16 SV251A SV251A
60 Manifold Washer 16 SV302GA SV302GA
61 Manifold Nut 16 SV251B SV251B
Port Option 2: Center Port
62 Manifold Discharge Elbow 2 PV236E KV236E
63 Manifold Inlet Elbow 2 PV237E KV237E
64 Manifold Tee 2 PV288 KV288
65 Manifold Tee O-Ring 4 V288BN V288TES V288XL V288ND V288VT
66 Manifold Tee Bolt 8 SV288B SV288B
67 Manifold Tee Washer 8 SV302GA SV302GA
68 Manifold Tee Nut 8 SV251B SV251B
69 Manifold Bolt 16 SV251A SV251A
70 Manifold Washer 16 SV302GA SV302GA
71 Manifold Nut 16 SV251B SV251B
3: EXP
VIEW
