Versa-Matic 2 Ultra-Matic Metallic Clamped - Manual (Page 11)

u2msmC-rev0314
www
.
versamatic
.
com Model U2 Metallic Clamped •
8
Composite repair Parts list
AIR VALVE ASSEMBLY
Item Description Qty Standard: Polypropylene
Air Valve Assembly 1 E200
(Includes items 1-10)
1
Valve Body 1 E200A
2 Valve Spool Assembly 1 E200B ASY (Includes U-Cups)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap Assembly 2 E500D ASY (Includes O-Rings)
5 End Cap Staple 2 E500F
6 Staple Retainer 2 E200L
7 Air Diverter 1 E200G
8 Valve Insert 1 E200H
9 Valve Gasket 1 E200J
10 Valve Cap Screw 4 P24-209
AIR END ASSEMBLY
Item Description Qty Standard: Polypropylene / Aluminum Option1: Polypropylene / Stainles
15 Center Block 1 E210 E210
16 Air Chamber Gasket 2 E212 E212
17 Air Chamber 2 E211 SE211
18 Air Chamber Bolt 12 V302G V181F
19 Air Chamber Nut 2 V354C SV354C
20 Air Chamber Washer 12 V302GA SV302GA
21 Bushing 2 E201MB E201MB
22 Pilot Shaft 1 E203A E203A
23 Pilot Shaft Spacer 5 P24-106P P24-106P
24 Pilot Shaft O-Ring 6 P24-107 P24-107
25 Stop Nut 2 P24-108 P24-108
26 Shaft Retainer – Left 1 E201B-L ASY (Includes O-Rings) E201B-L ASY (Includes O-Rings)
27 Shaft Retainer – Right (not shown) 1 E201B-R ASY (Includes O-Rings) E201B-R ASY (Includes O-Rings)
28 Shaft Retainer O-Ring 2 E201B-5 E201B-5
29 Shaft Retainer Screw 8 10-050 10-050
30 Exhaust Valve 2 E202 ASY E202 ASY
31 Exhaust Sleeve O-Ring 2 560.013.360 560.013.360
32 Retainer Plate Seal 2 P34-403 P34-403
33 Muffler Plate 1 E201H E201H
34 Muffler Plate Gasket 1 E200J-1 E200J-1
35 Muffler Plate Cap Screw 4 E201G E201G
36 Muffler Elbow 1 PE201N PE201N
37 Muffler 1 V20AEM V20AEM
38 Air Chamber O-Ring 2 P24-107 P24-107
DIAPHRAGM ASSEMBLY
Item Description Qty Rugged Dome Teflon Bonded Teflon 2-Piece
40 Main Shaft 1 P24-103 P24-103 P24-102 P24-102
41 Diaphragm Shaft Stud 2 N/A N/A V221F V221F
42 Inner Diaphragm Plate 2 V221B V226B V221TI V221TI
43 Outer Diaphragm Plate 2 VB221 SVB221 VB226 SVB226 V221TO SV221TO V221TO SV221TO
WVB221 HVB221 HVB226 HV221TO HV221TO
44 Diaphragm O-Ring 2 V221D N/A N/A N/A
V224BN V224N V225BN V225N
45 Diaphragm 2 V224ND V224VT V225ND V225VT V224TX V224TF
V224TPEXL V224TPEFG V225TPEXL V225TPEFG
46 Back-up Diaphragm 2 N/A N/A N/A V224TFB
WET END ASSEMBLY
Item Description Qty Standard: Option1: Option 2: Option 3:
Aluminum Stainless Steel Hastelloy Cast Iron
50 Water Chamber 2 V235 SV235 HV235 WV235
51 Large Clamp Bolt 4 V230C SV230C SV230C V230C
52 Large Clamp Nut 4 V230D SV230D SV230D V230D
53 Large Clamp Assembly 4 V230 SV230 SV230 V230
54 Valve Seat 4 V240BN V240N V240ND V240TPEFG V240TF V240VT
V240TPEXL V240A SV240 HV240 WV240
55 Valve Seat O-Ring (not shown) 4 V240T (Use with V240A, SV240, HV240, WV240 only)
56 Valve Ball 4 V241BN V241N V241ND V241P V241TPEXL V240TPEFG V241VT V240SS
57 Discharge Manifold 1 V236* SV236* HV236* WV236*
58 Inlet Manifold 1 V237F* SV237F* HV237F* WV237F*
59 Small Clamp Bolt 8 V239B SV239B V239B SV239B
60 Small Clamp Nut 8 V239C SV239C V239C SV239C
61 Small Clamp Assembly 8 V239 SV239 V239 SV239
OPTIONAL SCREEN BASE ASSEMBLY
Item Description Qty Standard: Aluminum
65 Screen Base 1 V238
66 Screen Base Inlet Manifold 1 V237
67 Inlet Cover 1 V242
68 Screen Base Bolts 3 V238A
* Add "BSP" for BSP threads.
