Val-Matic 14 and Larger Wafer and Lug Style Dual Disc Check Valve - Manual (Page 7)

REASSEMBLY (Continued) PARTS AND SERVICE
Parts and service are available from your local
representative or the factory. Make note of the
Valve Size and Model Number located on the valve
nameplate and contact:
5. While pushing the pin further, install the third
thrust bearing (6) and the fourth disc lug, and the
fourth thrust bearing (6). The pin should now be
centered in the body and the disc should rotate
without binding.
Val-Matic Valve and Manufacturing Corp.
905 Riverside Drive
6. Insert the disc stop pin (5) into the holes in the
body.
Elmhurst, IL 60126
Phone: (630) 941-7600
Fax: (630) 941-8042
7. Insert a sphere (9) into each of the four pin holes.
48” and larger valves have rubber washers instead
of spheres.
www.valmatic.com
A sales representative will quote prices for parts or
arrange for service as needed.
8. Place a small amount of pipe thread sealant such
as Loctite PST ont he retainer plugs (7 and 8) and
tighten into place. 48” and larger valves will have
o-rings for 2 of the plugs instead of tapered
threads.
9. Stand the valve on its edge with the pins vertical
and verify smooth operation of the valve before
installation into the pipeline. Apply a light coat of
silicone grease on the rubber seat for air service
valves (Series 8900).
6
LIMITED WARRANTY
All products are warranted to be free of defects in material and workmanship for a period of one year from the date of
shipment, subject to the limitations below.
If the purchaser believes a product is defective, the purchaser shall: (a) Notify the manufacturer, state the alleged defect and request
permission to return the product; (b) if permission is given, return the product with transportation prepaid. If the product is accepted
for return and found to be defective, the manufacturer will, at his discretion, either repair or replace the product, f.o.b. factory, within
60 days of receipt, or refund the purchase price. Other than to repair, replace or refund as described above, purchaser agrees that
manufacturer shall not be liable for any loss, costs, expenses or damages of any kind arising out of the product, its use, installation
or replacement, labeling, instructions, information or technical data of any kind, description of product use, sample or model,
warnings or lack of any of the foregoing. NO OTHER WARRANTIES, WRITTEN OR ORAL, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY, ARE MADE OR AUTHORIZED. NO
AFFIRMATION OF FACT, PROMISE, DESCRIPTION OF PRODUCT OF USE OR SAMPLE OR MODEL SHALL CREATE ANY WARRANTY
FROM MANUFACTURER, UNLESS SIGNED BY THE PRESIDENT OF THE MANUFACTURER. These products are not manufactured,
sold or intended for personal, family or household purposes.
®
