Reelcraft Series L4000 Spring Driven Cord Reels - Manual (Page 5)

Item
#
Description
#
Req.
L 4035
163 1
L 4050
163 1
L 4035
162 2
L 4050
162 2
L 4035
163 3
L 4050
163 3
L 4545
123 3
1 Incandescent Lamp/Cord Assembly 1 600223 600212 None None None None None
2 Fluorescent Lamp/Cord Assembly 1 None None 600207 600211 None None None
3 Duplex GFCI Box/Cord Assembly 1 None None None None None None None
4 Single Outlet 1 None None None None 600208 600209 600251
5 Inlet Cord Assembly 1 260517 260517 600213 600213 260517 260517 260630
6 Connector, 90° Cord 1 261140-1-C 261140-1-C 261140-1-C 261140-1-C 261140-1-C 261140-1-C 261140-C
7 Screw, Set 3/8-19 x 1/2” Pin 1 300006 300006 300006 300006 300006 300006 300006
8 Nut, Lock 10-32 Hex 22 S300011 S300011 S300011 S300011 S300011 S300011 S300011
9 Snap Ring 1 300031 300031 300031 300031 300031 300031 300031
10 Stud, Springcase 1 S261360 S261360 S261360 S261360 S261360 S261360 S261360
11 Screw, 10-32 x 1/2” 2 300002 300002 300002 300002 300002 300002 300002
12 Guide Arm Assembly 1 S400107 S400107 S400107 S400107 S400107 S400107 S400107
13 Bumper Assembly 1 A600193 A600193 A600193 A600193 A600193 A600193 A1-HR1004-A
14 Spring Arbor 1 S400017 S400017 S400017 S400017 S400017 S400017 S400017
15 Latch Cam 1 S400019 S400019 S400019 S400019 S400019 S400019 S400019
16 Sheave Disc 1 400006 400006 400006 400006 400006 400006 400006
17 Strain Relief 1 260501 260501 260501 260501 260501 260501 260633
18 Adapter, Plate 1 261577 261577 261577 261577 261577 261577 261577
19 Split Lock Washer 3 902016 902016 902016 902016 902016 902016 902016
20 Screw, 1/4-20 x 5/8” Hex 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
21 Collector Ring Assembly 1 602296 602296 602296 602296 602296 602296 602296
22 Cover 1 261723 261723 261723 261723 261723 261723 261723
23 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13 S140-13 S140-13
24 Wire Nut 3 260500 260500 260500 260500 260500 260500 260774
25 Grounding Cord Assembly 1 600241 600241 600241 600241 600241 600241 600283
26 Lock Washer 1 S115-10 S115-10 S115-10 S115-10 S115-10 S115-10 S115-10
27 Connect Terminal 1 260609 260609 260609 260609 260609 260609 260609
28 Terminal Block Assembly 1 600205 600205 600205 600205 600205 600205 600205
29 Sheave Assembly 1 600194 600194 600194 600194 600194 600194 600254
30 Screw, 10-32 x 3/8” 5 300001 300001 300001 300001 300001 300001 300001
31 Latch Plate Spring 1 S400018 S400018 S400018 S400018 S400018 S400018 S400018
32 Screw, 10-24 x 3/8” 1 S32-136 S32-136 S32-136 S32-136 S32-136 S32-136 S32-136
33 Screw 10-32 x 1” 1 300035 300035 300035 300035 300035 300035 300035
34 Latch Bumper 1 S400021 S400021 S400021 S400021 S400021 S400021 S400021
35 Latch Plate Assembly 1 S400109 S400109 S400109 S400109 S400109 S400109 S400109
36 Latch Bushing 1 S400012 S400012 S400012 S400012 S400012 S400012 S400012
37 Base Assembly 1 400101 400101 400101 400101 400101 400101 400101
38 Main Shaft Kit 1 602348 602348 602348 602348 602348 602348 602348
39 Spacing Washer 2 300034 300034 300034 300034 300034 300034 300034
40 Drive Spring Assembly 1 S400030 S400030 S400030 S400030 S400030 S400030 S400030
41 Spring Case Assembly 1 S400103 S400103 S400103 S400103 S400103 S400103 S400103
42 Nut, 10-32 x 3/8” Nyloc 1 S82-15 S82-15 S82-15 S82-15 S82-15 S82-15 S82-15
43 Guide Arm Switch Assembly 1 None None None None None None None
44 Roller Plate Assembly 1 None None None None None None None
45 Switch Box 1 None None None None None None None
46 Autoswitch Cord 1 None None None None None None None
47 Switch 1 None None None None None None None
48 Guide Arm 1 None None None None None None None
49 Spring 1 None None None None None None None
50 Fluorescent Lamp & Single Outlet 1 None None None None None None None
51 LED Lamp/Cord Assembly 1 None None None None None None None
52 Triple Tap/Cord Assembly 1 None None None None None None None
53 Flying Leads 1 None None None None None None None
Series L4000 Spring Driven Cord Reels
www.reelcraft.com Page 5
