Rapid-Air Corp.
Minarik Adjustable Speed Control models RG100UC and RG200UC

Specifications

Input voltage
RG100UC 115 vac, 50/60 hertz, single phase
RG200UC 230 vac, 50/60 hertz, single phase

Maximum input current
15.0 amperes

Output armature voltage
RG100UC 0-90 vdc
RG200UC 0-180 vdc

Output armature current
10.0 amperes

Output Field Voltage
RG100UC 100 vdc
RG200UC 200 vdc

Output field current
1.0 ampere

Weight
3.1 pounds

Ambient Temperature Range
10-50 degrees C

Load regulation
With tachometer feedback 0.5% of base speed
Without tachometer feedback 8% of base speed

Horsepower rating
RG100UC 1/4 through 1 hp
RG200UC 1/2 through 2 hp
