ASUS GigaX 1124 5
English
Table 3 LED indications in VCT mode
LED Color Status Description
SYSTEM Green On The switch is on.
Red On The switch is initializing or VCT is in
progress.
Off The switch is off.
1 – 24 Port numbers
STATUS Green On The port is selected to execute VCT.
(Port Select) Blinking VCT on the port is in progress.
Off
The port is not selected.
SPEED Green On The pair is shorted.
(Pairs 1, 3) Amber On The pair is open (the cable is not attached
to any device).
Blinking The port failed to execute VCT.
Off
VCT is in progress (PORT SELECT LED
is blinking)
OR
No error is found (PORT SELECT LED
is green)
DUPLEX Green On The pair is shorted.
(Pairs 2, 4) Amber On The pair is open (the cable is not attached
to any device).
Blinking The port failed to execute VCT.
Off
VCT is in progress (PORT SELECT LED
is blinking).
OR
No error is found (PORT SELECT LED
is green).
NOTE. The number of lighted LEDs on Pairs 1 ~ 4 shows the distance
from the switch to the defective point (1 LED = 10 meters).
4
3
5
7
6
