Recognizing buttons and controls
R
ec
og
niz
ing
b
utt
on
s a
nd
co
ntr
ols
Rear Panel Input / Output Connections
Input V ideo Speakers
A V1 Composite Stereo / AUDIO Connector
A V2 S-V ideo Stereo / AUDIO Connector
A V3 Y ,Cb,Cr Stereo / AUDIO Connector
PC VGA (15 Pin D-SUB) Stereo /3.5 Earphone Connector
TV Antenna T erminal Antenna Connector
Output V ideo Speakers
Headphone None Stereo
Connectors
Input Connectors
earphone
(3.5 )
speakers speakers
Output Connectors
