3 Customer Hotline 1-800-445-1805
BEFORE YOU CAN RUN YOUR NEW GENERATOR, FOLLOW THESE SIMPLE INSTRUCTIONS:
THE FOLLOWING ITEMS MUST BE REMOVED BEFORE RUNNING YOUR NEW GENERATOR. IN ORDER TO PROTECT YOUR
GENERATOR THESE ITEMS HAVE BEEN ADDED TO ENSURE SAFE DELIVERY OF YOUR NEW GENERATOR.
CAUTION: FAILURE TO REMOVE THESE ITEMS CAN RESULT IN DAMAGE TO YOUR GENERATOR, POSSIBLE
PERSONAL INJURY AND VOID YOUR WARRANTY.
REFER TO THE FOLLOWING INSTRUCTIONS AND PICTURES TO REMOVE THE ATTACHED ENGINE SUPPORT BRACKET UNDER
THE ENGINE AND THE RUBBER ISOLATOR SUPPORT BRACKET UNDER THE ALTERNATOR.
TIP THE GENERATOR BACK ONTO ITS RECOIL
FRAME END AS INDICATED IN THIS PICTURE.
REMOVE THE INDICATED BOLTS AND
NUTS FROM THE YELLOW ENGINE SUPPORT
BRACKET. YOU MAY USE THE APPROPRIATE
WRENCHES PROVIDED.
YOU MAY DISCARD THIS BRACKET, AS IT
IS NO LONGER REQUIRED FOR NORMAL
OPERATION OF YOUR GENERATOR.
ALSO, REMOVE THE RUBBER ISOLATOR SUPPORT
BRACKET AS INDICATED IN THIS PICTURE. LOOSEN
AND REMOVE THE BOTTOM NUT. THEN, MOVE THE
TOP NUT UP THE BOLT WITH YOUR FINGER AND
REMOVE THE ISOLATOR BY TAPPING IT OUT OF THE
SLOT. YOU MAY DISCARD THIS ISOLATOR, AS IT IS
NO LONGER REQUIRED.
YOUR GENERATOR IS NOW READY FOR USE. REFER TO YOUR OWNER'S MANUAL FOR PROPER OIL FILL AND STARTUP
INSTRUCTIONS.
REMOVAL OF SHIPPING SUPPORTS REMOVAL OF SHIPPING SUPPORTS
Model: PM0103008
THIS IS THE RECOIL END OF YOUR
GENERATOR. BEFORE FILLING THE
ENGINE WITH OIL, TIP IT BACK TO
ACCESS THE ENGINE SUPPORT
BRACKET AND ISOLATOR SUPPORT
BRACKET AS SHOWN IN THE
FOLLOWING PICTURE. PLACE THE
GENERATOR ON THE FLATTENED
CARDBOARD BOX OR OTHER
PROTECTIVE SURFACE.
RUBBER ISOLATOR SUPPORT
BRACKET
ENGINE SUPPORT BRACKET
REMOVE THESE 4 NUTS
& BOLTS AS INDICATED.
SUPPLIED WRENCHES
REMOVE THIS ISOLATOR SUPPORT
BRACKET WITH THE SUPPLIED WRENCH
LOOSEN AND REMOVE
THIS NUT.
