FRAME ASSEMBLY
6
and base rails as shown, making sure that all pieces snap into place. (Figure 2)
2. Position top cover but do not secure with bungee balls until later. Install vertical posts
1. Install vinyl end panels and secure with bungee balls. (Figure 1)
FIGURE 1
FIGURE 2
IMPORTANT NOTE:
WEAR EYE PROTECTION WHEN
INSTALLING BUNGEE BALLS.
END
PANEL
(2)
BUNGEE
BALL
TOP
COVER
VERTICAL
POST
(6)
BASE RAIL, MALE
(2)
BASE RAIL, FEMALE
(2)
