Bungee installation – Poly-Tex CC5000 User Manual
Page 10
BUNGEE BALL
WHEN REINSTALLING, INSPECT BUNGEE BALLS
FOR WEAR OR DAMAGE. DO NOT USE
DAMAGED BUNGEE BALLS.
BUNGEE INSTALLATION
9
A BUNGEE MAY SLIP OFF IF FABRIC IS NOT TAUT.
OCCASIONALLY CHECK YOUR INSTALLATION TO
ENSURE ALL BUNGEES REMAIN ATTACHED.
SEE ALTERNATE ATTACHMENTS BELOW, WHICH
MAY HELP.
ONCE IN PLACE, MOVE BUNGEE SO BALL IS NEAR
GROMMET.
WRAP AROUND
TYPICAL INSTALLATION
ALTERNATE
INSTALLATION
PASS THE LOOP THROUGH THE BALL
(OPPOSITE OF THE TYPICAL)
THROUGH LOOP
PULL TIGHT
THEN FORCE THE BALL BEHIND
THE LOOP
