IOVU-572M Panel PC

Page 4

I/O and Communications

Ethernet

2 x 10/100 Mb/s

Serial Ports

1 x RS-232/422/485

USB Interfaces

2 x USB host connectors

Audio

2 x 1.5 Watt speakers

LED Function

1 x Power ON/OFF LED on front panel

Memory Socket

SD Card socket

Power

Power Supply

12-36 VDC

Power Consumption

12 W or less

Environmental and Mechanical

Operating Temperature

Minimum: -10ºC (14°F)

Maximum: 60°C (140°F)

Storage Temperature

Minimum: -20ºC (-4°F)

Maximum: 70°C (158°F)

Humidity

5%RH to 90%RH (non-condensing)

Vibration

Operating Random Vibration Mode

1.Axes: 3 axs (Vertical / Transverse / Longitudinal).

2.10-500 Hz, 60min/axis.

3.Equivalent to Z:2.18 Grms X:1.6 Grms Y:1.96 Grms

Front Panel Color

Pantone Black C

Physical Dimensions

180 mm x 135.8 mm x 46.7 mm

Ingress Protection

IP 64 compliant front panel

Table 1-1: Technical Specifications
