AFL-08B-N270 User Manual

Page 54

Figure 3-5: DDR2 SO-DIMM Module Installation

3.5 CF Card Replacement

The AFL-08B-N270 has one CF Type II slot. Follow the instructions below to replace the

CF card.

Step 1:

Follow all anti-static procedures

. See Section A.1.2.

Step 2:

Turn off the power

. See Section 3.1.

Step 3:

Follow the instruction listed in Section 2.3 to replace the CF card.

Step 0:

3.6 Reinstalling the Covers

WARNING:

Failing to reinstall the covers may result in permanent damage to the

system. Please make sure all coverings are properly installed.

WARNING:

Over-tightening rear cover screws will crack the plastic frame.

Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).
