CF1: Compact Flash Storage Card Socket

PIN Description PIN Description

1

GROUND

26

IDE_DETECT

2

DATA 3

27

DATA 11

3

DATA 4

28

DATA 12

4

DATA 5

29

DATA 13

5

DATA 6

30

DATA 14

6

DATA 7

31

DATA 15

7

CS1#

32

CS3#

8

N/C

33

N/C

9

GROUND

34

IOR#

10

N/C

35

IOW#

11

N/C

36

VCC

12

N/C

37

IRQ15

13

VCC

38

VCC

14

N/C

39

MASTER

15

N/C

40

N/C

16

N/C

41

RESET#

17

N/C

42

IORDY

18

SA2

43

DMARQ

19

SA1

44

DMACK#

20

SA0

45

ACTIVE#

21

DATA 0

46

PDIAG#

22

DATA 1

47

DATA 8

23

DATA 2

48

DATA 9

24

N/C

49

DATA 10

25

IDE_DETECT

50

GROUND

LED Indicator

Location Status

Description

LED1 Red

Power

Linked

LED2 Green

SATA

Linked

LED3 Green

HDD

Activity
