background image

3

Jumpers Setting and Connectors

PW1: Power Connector

PIN Description

1 N/C
2 GND
3 GND
4 +5V

SATA1: Serial ATA Connector

PIN Description

1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND

IDE2: 2X20 Pin IDE Connector (P=2.54)

PIN Description PIN Description

1

RESET#

2

GROUND

3

DATA 7

4

DATA 8

5

DATA 6

6

DATA 9

7

DATA 5

8

DATA 10

9

DATA 4

10

DATA 11

11

DATA 3

12

DATA 12

13

DATA 2

14

DATA 13

15

DATA 1

16

DATA 14

17

DATA 0

18

DATA 15

19

GROUND

20

N/C

21

DMARQ

22

GROUND

23

IOW#

24

GROUND

25

IOR#

26

GROUND

27

IORDY

28

GROUND

29

DMACK#

30

GROUND

31

INTERRUPT

32

N/C

33

SA1

34

PDIAG#

35

SA0

36

SA2

37

HDC CS0#

38

HDC CS1#

39

HDD ACTIVE#

40

GROUND
