9
2.4 COM Port I/O base address setting
• JP10: COM Port I/O base address setting
Base Address 11-12 9-10 7-8 5-6 3-4 1-2
*200-207H ON ON ON ON ON ON
208-20FH ON ON ON ON ON OFF
210-217H ON ON ON ON OFF ON
218-21FH ON ON ON ON OFF OFF
220-227H ON ON ON OFF ON ON
228-22FH ON ON ON OFF ON OFF
230-237H ON ON ON OFF OFF ON
238-23FH ON ON ON OFF OFF OFF
240-247H ON ON OFF ON ON ON
248-24FH ON ON OFF ON ON OFF
250-257H ON ON OFF ON OFF ON
258-25FH ON ON OFF ON OFF OFF
260-267H ON ON OFF OFF ON ON
268-26FH ON ON OFF OFF ON OFF
270-277H ON ON OFF OFF OFF ON
278-27FH ON ON OFF OFF OFF OFF
280-287H ON OFF ON ON ON ON
288-28FH ON OFF ON ON ON OFF
290-297H ON OFF ON ON OFF ON
298-29FH ON OFF ON ON OFF OFF
2A0-2A7H ON OFF ON OFF ON ON
2A8-2AFH ON OFF ON OFF ON OFF
2B0-2B7H ON OFF ON OFF OFF ON
2B8-2BFH ON OFF ON OFF OFF OFF
2C0-2C7H ON OFF OFF ON ON ON
2C8-2CFH ON OFF OFF ON ON OFF
2D0-2D7H ON OFF OFF ON OFF ON
2D8-2DFH ON OFF OFF ON OFF OFF
2E0-2E7H ON OFF OFF OFF ON ON
2E8-2EFH ON OFF OFF OFF ON OFF
2F0-2F7H ON OFF OFF OFF OFF ON
2F8-2FFH ON OFF OFF OFF OFF OFF
300-307H OFF ON ON ON ON ON
308-30FH OFF ON ON ON ON OFF
310-317H OFF ON ON ON OFF ON
