5
2
Installation
This chapter describes how to install the PM-1028.
2.1 Hardware Installation
Installation of the PC/104 modules on CPU card is quick and
simple. The following steps describe how to mount the PC/104
modules.
Note: Ground yourself to remove any static charge before
touching your PM-1028. You can do it by using a grounded wrist
strap at all times or by frequently touching any conducting
materials that are connected to the ground.
1. Turn the power off
2. Plug the PC/104 module in to the connectors on the CPU
card carefully
3. Secure the PC/104 module with the four mounting spacers
and screws
4. Set the jumper settings
5. Attach the cables
6. Turn the power on
