3.2 PC/104 Expansion Bus
The PC/104 expansion bus on the enables you to attach it to the
PC/104 slot of a target system. The PC/104 bus has already
become an industrial embedded PC bus standard, so you can
easily install thousands of PC/104 modules from hundreds of
vendors in the world. There are two types of connectors on this
board -- PC/104-64 and PC/104-40.
PC/104-40 Connector
PIN NO DESCRIPTION PIN NO DESCRIPTION
D1 GND C1 GND
D2 MCS16# C2 SBHE#
D3 IOCS16# C3
LA23
D4 IRQ10 C4 LA22
D5 IRQ11 C5 LA21
D6 IRQ12 C6 LA20
D7 IRQ15 C7 LA19
D8 IRQ14 C8 LA18
D9 DACK0# C9
LA17
D10 DRQ0 C10 MEMR#
D11 DACK5# C11 MEMW#
D12 DRQ5 C12 SD8
D13 DACK6# C13
SD9
D14 DRQ6 C14 SD10
D15 DACK7# C15
SD11
D16 DRQ7 C16 SD12
D17 VCC C17 SD13
D18 MASTER# C18
SD14
D19 GND C19 SD15
D20 GND C20 GND
