IEI Integration VGA-LVDS - Manual (Page 3)

3
Table of Connectors
LABEL FUNCTION
LVDS1 LVDS Panel Connector
INV 1 LVDS1 Backlight Control
KEY1 LVDS1 Backlight Adjust
JP3 VGA-LVDS Connector
LVDS1 : LVDS LCD Connector.
PIN No
DESCRIPTION PIN No DESCRIPTION
1 GND 2 GND
3 1st LVDS data0 output + 4 1st LVDS data0 output
5 1st LVDS data1 output + 6 1st LVDS data1 output
7 1st LVDS data2 output + 8 1st LVDS data2 output
9 1st LVDS clock output + 10 1st LVDS clock output
11 1st LVDS data3 output + 12 1st LVDS data3 outpu
13 GND 14 GND
15 2sd LVDS data0 output + 16 2sd LVDS data0 output
17 2sd LVDS data1 output + 18 2sd LVDS data1 output
19 2sd LVDS data2 output + 20 2sd LVDS data2 output
21 2sd LVDS clock output + 22 2sd LVDS clock output
23 2sd LVDS data3 output + 24 2sd LVDS data3 output
25 GND 26 GND
27 +LCD (3.3V,5V) 28 +LCD (3.3V,5V)
29 +LCD (3.3V,5V) 30 +LCD (3.3V,5V)
INV1: LVDS1 Backlight Control
PIN No
DESCRIPTION PIN No DESCRIPTION
1 BLADJ# 2 GND
3 12V 4 GND
5 BLEN#
KEY1: LVDS1 Backlight Adjust
PIN No
DESCRIPTION PIN No DESCRIPTION
1 LED-B L 2 N/A
3 LED-AM 4 menu/enter
5 DOWN 6 UP
7 auto/exit 8 POWER
9 GND
