VGA1 : 15-pin Female Connector
PIN DESCRIPTION
PIN DESCRIPTION
1 RED 2 GREEN
3 BLUE 4
NC
5 GND 6 GND
7 GND 8 GND
9 NC
10 GND
11 NC 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDCCLK
LVDS2: LVDS Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND1 2 GND2
3 A_Y0 4 A_Y0#
5 A_Y1 6 A_Y1#
7 A_Y2 8 A_Y2#
9 A_CK 10 A_CK#
11 A_Y3 12 A_Y3#
13 GND3 14 GND4
15 NC 16 NC
17 VDD5 18 VDD5
19 VDD5 20 VDD5
