Feature:
z Provide VGA option for dual VGA display output
z Resolution supported 1366x768, 1024x768, 800x600, 640x480
z
18 or 24 bits LVDS to VGA converter board
Ordering Information
LVDS-VGA02-R10:
18/24 bit LVDS to VGA Converter board
32602-012200-100-RS
20 to 30pin LVDS connecting cable for WAFER-PV-D5252 only
32602-012300-100-RS
20 to 20pin LVDS connecting cable
Support model
WSB-PV-D5251 PICOe-PV-D5251 PCISA-PV-D5251
KINO-PV-D5251 NOVA- PV-D5251 NANO-PV-D5251
NANO-PV-D5252 WAFER-PV-D5252
Table of Connectors
LABEL FUNCTION
LVDS2
LVDS Panel Connector
JP2 SMBus connector
VGA1 VGA connector
JP2: SMBus Connector
PIN NO.
DESCRIPTION
1 NC
2 SMB_DATA
3 SMB_CLK
4 NC
