IEI Integration DP-LVDS - Manual (Page 4)

4
LVDS2: LVDS Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 A_Y0 4 A_Y0#
5 A_Y1 6 A_Y1#
7 A_Y2 8 A_Y2#
9 A_CK 10 A_CK#
11 A_Y3 12 A_Y3#
13 GND 14 GND
15 B_Y0 16 B_Y0#
17 B_Y1 18 B_Y1#
19 B_Y2 20 B_Y2#
21 B_CK 22 B_CK#
23 B_Y3 24 B_Y3#
25 GND 26 GND
27 VCC/VCC3 28 VCC/VCC3
29 VCC/VCC3 30 VCC/VCC3
INV2 : 5-pin Header Inverter Connector
PIN NO. DESCRIPTION
1 LCD_BKLTCTL
2 GROUND
3 +12V
4 GROUND
5 BACKLIGHT ENABLE
JP2: LVDS1 Voltage Selection
PIN NO. DESCRIPTION
Short 1-2 +3.3V LVDS(default)
Short 2-3 +5V LVDS
