NOVA-HM551 5.25" SBC
Page 8
Specification NOVA-HM551
Display Ports One internal VGA port (10-pin box header)
Two HDMI port (up to 1080p)
One internal 18/24-bit dual-channel LVDS connector
Ethernet Two RJ-45 GbE ports
Serial Ports Four RS-232 via one 40-pin header
Two RS-232/422/485 via two 14–pin headers
USB 2.0/1.1 Ports Eight internal USB ports via four 8-pin headers
Parallel Port One internal parallel port via one 26-pin header
Keyboard/Mouse One keyboard/mouse connector via one 6-pin wafer
Fan Connectors One 4-pin CPU fan connector
One 3-pin system fan connector
SMBus One SMBus connector via one 4-pin wafer
Storage
Serial ATA Four SATA 3.0 Gb/s connectors
Two 5V SATA power connectors
Environmental and Power Specifications
Power Supply 12 V only
ATX and AT power supported
Power Connector One internal 4-pin Molex power connector for power supply
Power Consumption [email protected] (2.66 GHz Intel® Core™ i7 620M CPU with two
1333 MHz 4 GB DDR3 SO-DIMMs)
Operating Temperature -10ºC ~ 60ºC (requires cooler and silicone heat sink paste)
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 203 mm x 146 mm
Weight GW/NW 800 g / 300 g
Table 1-1: Technical Specifications
