Disable D EFAULT The real time clock (RTC) cannot generate a wake
event
5.7 PnP/PCI Configurations
Use the PnP/PCI Configurations menu (
696H696H696H
BIOS Menu 15) to set the plug and play, and
PCI options.
BYOSOFT BIOS Setup Utility
PnP/PCI Configurations
DMA Channel 0
DMA Channel 1
DMA Channel 3
DMA Channel 5
DMA Channel 7
IRQ3
IRQ4
IRQ5
IRQ7
IRQ10
IRQ11
Reserved Memory Address
Item
Help
___________________
Reserve specified
DMA Channel for ISA
devices.
↑ ↓=Move Highlight =Select Entry F10=Save Esc=Exit Without Save
F1=Scroll Help F9=Reset to Defaults
BIOS Menu 15: PnP/PCI Configurations
DMA Channel# [Available]
Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP
device.
Available D EFAULT The specified DMA is available to be used by
PCI/PnP devices
Reserved The specified DMA is reserved for use by Legacy
ISA devices
Available DMA Channels are:
