IMB-Q670 Micro-ATX Motherboard
Page 106
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [ON]
On-Chip GbE Configuration
GbE Controller [Enabled]
GbE PXE Boot [Disabled]
Wake on Lan from S5 [Enabled]
Wake Event Configuration
Resume on PCIE Wake [Enabled]
Resume on PCIE PME [Enabled]
Resume on Ring [Enabled]
Resume on PS/2 [Enabled]
Audio Configuration
Azalia HD Audio [Enabled]
Azalia internal HDMI codec [Enabled]
PCI Express Ports Configuration
PCIe x4 Slot1 [Enabled]
PCIe LAN Controller [Enabled]
PCIe LAN PXE Boot [Enabled]
PCIe USB3.0 Controller [Enabled]
PCIe x4 Slot2 [Enabled]
Enabled/Disabled GbE
Controller. Before
disabling GbE, AMT
function must be
disabled.
---------------------
: Select Screen
 : Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19: Southbridge Chipset Configuration
 GbE Controller [Enabled]
Use the GbE Controller option to enable or disable the GbE controller. Before disabling
the GbE controller, the AMT function must be disabled.

Disabled The onboard GbE controller is disabled

Enabled D EFAULT The onboard GbE controller is enabled
 GbE PXE Boot [Disabled]
Use the GbE PXE Boot option to enable or disable the boot option for GbE devices.

Disabled D EFAULT Disables the GbE PXE Boot option

Enabled Enables the GbE PXE Boot option
