PX-9S User’s Manual
Pin Assignment
P8/P9(PW1)
PIN NAME
1 PWR OK
2 +5V
3 +12V
4
-12V
5 GND
6 GND
7 GND
8 GND
9 -5V
10 +5V
11 +5V
12 +5V
ATX control
connector(CN2)
PIN NAME
1 STB5V
2 PS_ON
3 GND
Fan connector(CN3,CN5)
PIN NAME
1 NC
2 +12V
3 GND
ATX(PW2)
PIN NAME PIN NAME
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 GND 13 GND
4 +5V 14 PS_ON
5 GND 15 GND
6 +5V 16 GND
7 GND 17 GND
8 PWR OK 18 -5V
9 STB5V 19 +5V
10 +12V 20 +5V
Power Extension(CN1)
PIN NAME
1 +5V
2 +5V
3 -5V
4 -12V
5 +12V
6 +3.3V
7 GND
8 GND
