User’s Manual
4.6.2 Dome Protocol Setup
The Dome Protocol item lists the available dome protocols for communicating
with dome cameras connected to the DRT16 / DRT8 DVR. From the Main
menu, select and press ENTER. The following menu is
displayed.
Camera Setup
1. Camera Select
2. Dome Protocol
3. Dome ID
4. Camera Title
5. Covert
6. Termination
7. Brightness
8. Contrast
9. Saturation
10. Hue
CH1
None
0
NO
NO
0
0
0
0
To configure dome protocol, select a camera first and set the communications
protocol associated with dome camera using the Direction keys and ENTER.
The available protocol includes , , ,
, and (default).
NOTE:
The settings become effective after saving the changes and
exiting from the menu.
4.6.3 RS485 Setup
DRT16 / DRT8 DVR
controls the domes via RS-485 communication protocol.
The RS-485 parameters in DRT16 / DRT8 DVR must be set to the same
parameters as the protocol for RS-422 setup of the dome.
Users are allowed to change the RS-485 settings of the DRT16 / DRT8 DVR.
Select in Main menu, then select from the
System Setup menu and press ENTER. The following menu is displayed.
RS485 Setup
1 Unit ID
2 Baud Rate
3 Bits
4 Stop
5 Parity 224
9600
8
1
None
31
