Page 9

Functions
9
Version 1.2
4.6
Image Memory for 9 images
The SCB-12 has an image memory from which a stored
image can be output as a still image.
You can store up to 9 images in the memory.
Code
Storing an image: Press one of the MEMORY keys for 2
seconds or more
Recalling an image: Press one of the MEMORY keys
quickly
Splitscreen
By pressing the ALL key a split image with all 9 pictures
of the memory can be displayed.
4.7
Freeze
To capture the current image into memory, use the
FREEZE-key. The captured image is output.
4.8
Image Turn Mode
Picking up a complete vertical (portrait) document or A4
page has always been a critical issue because the
image was always picked up in a horizontal (landscape)
format.
The camera could only use 50% of its pixels to pick up
a vertical (portrait) page. WolfVision's "Image turn"
mode solves this problem.
Just place your document (or other vertical object) on
the working surface horizontally. Zoom in on it com-
pletely, so that approx. 90% of the pixels of the built-in
camera are used to pick up the document. Press the
IMAGE TURN key. The SCB-12 turns the picture elec-
tronically at an angle at 90º and outputs it correctly with
a much higher resolution than in normal mode. The left
and right margins are blackened out.
Example of a splitscreen
for higher resolution
