Vortexx SJ & XJ Series - Manual (Page 15)

Plunger Pumps
Operating Instructions and Parts Manual
SJ & XJ Series Pumps
First Choice When Quality Matters
NORTH
AMERICA
Pos. Code Description Qty. Pos. Code Description Qty.
1 1981780 Knob 1
2 1980300 Nut 1
3 1980470 Adjusting screw 1
1980390 Handle insert 1
4
1980540 Handle insert
- EZ Start
1
5 1080070 Pin 2
6 1980220 Plate spring 2
7 1271070 Spring 1
8 1080041 Upper piston 1
9 1080401 Back-up ring 1
10 1080250 O-Ring
Ø 7.66x1.78
1
11 1980210 Piston guide 1
12 880830 O-Ring
Ø 15.54x2.62
7
13 740290 O-Ring
Ø 14x1.78
1
14 800560 O-Ring
Ø 8.73x1.78
1
15 1271170 Back-up ring 1
16 1080190 O-Ring
Ø 2.9x1.78
2
17 1271160 Lower piston 1
18 1980200 Valve seat 1
19 1470210 O-Ring
Ø 9x1
1
20 880581 Plug
1/4” G
2
21 820510 O-Ring
Ø 10.82x1.78
2
22 620301 Plug
1/8” G
1
23 1980310 Head bolt
M10x65 (443 in/lbs)
3
24 650530 Lockwasher 3
1982450 Pump head
brass
1
25
1982740 Pump head
- EZ Start
26 1260162 Valve cap
(443 in/lbs)
3
27 960160 O-Ring
Ø 17.86x2.62
3
28 1269050 Valve assembly 3
29 1982520 Hose tail 1
30 480480 O-Ring
Ø 4.48x1.78
1
31 1250280 Ball 1
32 1560520 Spring 1
33 1460430 O-Ring
Ø 4x2.5
1
34 1540170 Check valve 1
35 1080091 Spring 1
36 394280 O-Ring
Ø 12.42x1.78
1
37 1200690 O-Ring
Ø 15.6x1.78
1
38 1270141 Injector adapter 1
40 1989050 Inlet valve 3
41 1342761 Gasket 3
42 1981570 Piston guide 3
43 770260 O-Ring
Ø 23.52x1.78
3
44 1260440 Gasket 3
45 1981580 Ring 3
46 1980410 Oil seal 3
47 770090 O-Ring
Ø 5.28x1.78
1
48 1983050 Pump housing 1
49 740290 O-Ring
Ø 14x1.78
1
50 1980380 Oil cap 1
53 180030 Bolt
M8x20 (228 in/lbs)
4
54 1981140 Spring 3
55 1981120 Piston mru 3
55 1980140 Piston ln 3
56 1980150 Spring retainer 3
57 1983100 Rail 1
58 1980250 Bearing 1
59 1980240 Thrust washer 1
1982710 Hollow shaft ml 1
1982810 Hollow shaft rn 1
61
1982840 Hollow shaft  1
61 1980050 Hollow shaft u 1
63 1980340 O-Ring
Ø 83.8x2.62
1
64 1981420 Flange
F7
1
65 1982360 Rear bearing 1
66 1140380 Seal 1
67 1980430 Spacer 3
77 1981130 Plunger shoe ln 3
78 1981770 Knob plug 1
79 1982560 Screw TE M6x8
- EZ Start
1
80 1982570 Washer Øi6.3
- EZ Start
1
81 1982440 Crub screw M8x8
- EZ Start
1
82 1982240 Ball
- EZ Start
1
83 1981800 Spring
- EZ Start
1
AR64545 Oil 1
O
il
C
apaCity
- 4.5
Oz
Legend
For l For n For 
SJV2G25 SJV2.5G24 SJV3G25
SJV2.5G25 SJV3G27
SJV2.5G26
SJV2.5G27
Legend
For m For r For 
XJV2G15 XJV2.5G15 XJV3G15
XJV2G20 XJV2.5G20 XJV3G20
XJV2.5G22 XJV3G22
For u
XJV3.5G22
