Audiovox PA-S450 - Manual (Page 10)

RCATYPE
SHIELDEDCABLES
(NOTINCLUDED)
4-PIN
CONNECTORS
IMPORTANT
USEEITHERHIGH-LEVELOR
LOW-LEVEL INPUTS, NOT BOTH.
HIGH-LEVEL
(SPEAKER) OUTPUTS
CAR STEREO
USE THIS INPUT WIRING WITH
OUTPUT WIRING ON PAGE 9
-8-
3-CHANNEL INPUT WIRING DIAGRAM
3 4 3 2
LOW-LEVEL
RCAOUTPUTS
WHITE
w/BLACK
STRIPE
WHITE GRAY
GRAY
w/BLACK
STRIPE
1
WHITE
w/BLACK
STRIPE
WHITE GRAY
GRAY
w/BLACK
STRIPE
LEFT +
LEFT -
RIGHT +
RIGHT -
RIGHT
LEFT
2
4 5 5
TO CH1
TO CH2
TO CH4
TO CH3
MONO OR
SUBWOOFER
MONO OR SUBWOOFER -
MONO OR
SUBWOOFER +
"Y"CABLE
