Assembly of Your TV4
Assembly:
As shown above, simply insert the receiving
elements into the center control arm and hand-
screw the center cap, making sure you have
a snug fit.
TV4
2
About Your TERK TV4
Thank you for choosing the TERK TV4. TERK antennas are
designed to help deliver sharp, clear video reception. At
TERK, our engineering department is dedicated to
designing antennas that enhance both the latest
technology and the aesthetics of any viewing environment.
The TV4 installs in minutes, is easy to use and simple to
adjust. Before using your antenna, please remove all parts
from the box and read the owner’s manual carefully.
The TV4’s unique and patented “Complentary Symmetry”
technology utilizes two tuned elements, which have a large
capacity for receiving VHF and UHF signals. This results
in more stations with less noise and “ghosting” than
conventional antennas. This unique design allows the
antenna to stand only 4
3 /
4
" tall, rather than the standard
36” - 42" length of traditional rabbit ears. The TV4 is
easy to adjust, requiring only a slight rotation to obtain
best reception.
TV4
1
media antenna on
media ant enn a on
1
2
3
4
media antenna on
1. Receiving Elements
2. Center Cap 3. Coaxial Cable
4. Center Control Arm
