8
QPHY-USB Operator’s Manual Rev F
Equipment list
USB testing requires a number of probes and additional USB devices. The High-Speed receiver sensitivity
test requires a digital pattern generator. The following equipment is required for High-Speed, Full-Speed, and
Low-Speed USB testing:
High-Speed / Full-Speed / Low-Speed Tests Full-Speed / Low-Speed Tests
SDA (Serial Data Analyzer) Series
DDA (Disk Drive Analyzer) Series
WaveMaster Series (3 GHz bandwidth or higher)
WavePro 7300A, 7200A
WaveRunner 6200A, 204Xi, including "MXi" models
WavePro 7xxZi (2 GHz bandwidth or higher)
WavePro 7100A, 7000A
WaveRunner 104Xi, 64Xi, 44Xi, including "MXi" models
WaveRunner 6100A, 6050A
WavePro 715Zi
LeCroy equipment
• USB test fixture (LeCroy TF-USB-B)
• 2 GHz or higher bandwidth active differential probe (LeCroy WL300/D350ST-SP) [for HS tests]
o
LeCroy WL600/D600ST-SP recommended (but not mandatory) for WM-class oscilloscopes
o
A second differential probe is required for Hub testing
• 2 GHz (or higher) active probe (LeCroy HFP2500, 2 ea.) [for HS/FS/LS tests]
•
1.5 GHz (or lower) active probe (HFP1500) or passive probe (PP006A or equivalent) [for FS/LS tests]
o
PP00x passive probe will require AP-1M adapter for WM-class oscilloscopes
• 30A or lower Current probe (LeCroy CP030) [for B.4 Inrush test only]
o
Adapter (AP-1M) required for WM-class oscilloscopes
Additional equipment
• Certified High-Speed USB self-powered hub (4 ea.) [for FS/LS tests]
•
Certified Full-Speed USB self-powered hub [for FS/LS tests]
• 5 meter USB cables type-A to type-B male (6 ea.) [for FS/LS tests]
•
1 meter USB cables type-A to type-B male (up to 12, depending on hub under test) [for HS/FS/LS tests]
•
Certified Low-Speed trigger device (e.g. USB mouse) [for LS tests]
• Certified Full-Speed (or High-Speed) trigger device (e.g. USB memory stick or web camera) [for FS tests]
•
Certified High-Speed trigger device (can be used as the FS Certified device) [for HS tests]
•
Digital Voltmeter 3 ½ digits (Keithley 2000 multimeter or equivalent) [for HS/FS/LS tests]
• Data Pattern Generator (e.g 2 x Tabor WW1281A with synchronization cable) [for HS tests]
• USB host system [for HS/FS/LS tests]
No cost equipment
• MATLAB runtime component ( http://www.lecroy.com/goto/matlabmcrinstaller77/ )
•
USB High-Speed Electrical Test Tool software ( www.usb.org/developers/tools/USBHSET.exe )
