QPHY-BroadR-Reach Software Option
INTRODUCTION TO QUALIPHY BROADR-REACH
QPHY-BroadR-Reach is an automated test package performing all of the normative real time
oscilloscope tests for sources in accordance with the BroadR-Reach Physical Layer Transceiver
Specification For Automotive Applications, v.2.0.
The software can be run on any Teledyne LeCroy Zi and Xi Series oscilloscope with at least 1 GHz
bandwidth and a sample rate of at least 10GS/s (WaveRunner series and up). The oscilloscope must
also be equipped with QPHY-BroadR-Reach and either the JTA2 (standard on all Zi series
oscilloscopes), SDAII, or SDAIII options.
Required Equipment
• Real time Teledyne LeCroy Oscilloscope meeting the above requirements (at least 1 GHz
bandwidth, and sample rate of at least 10GS/s)
o All LabMaster 9 Zi-A oscilloscopes
o All SDA/DDA/WaveMaster 8 Zi-A oscilloscopes
o SDA/DDA/WavePro 725Zi-A and higher bandwidth oscilloscopes
o WaveRunner 610 Zi and higher bandwidth oscilloscopes
o WaveRunner 104 MXi-A /Xi-A Series and higher bandwidth oscilloscopes
Note: If a WaveRunner Xi oscilloscope is being used, the XWEB option is additionally
required.
• QPHY-BroadR-Reach and either the JTA2, SDAII, or SDAIII options
Note: SDA software is included on all SDA and DDA oscilloscope models. JTA2 is
standard on all Zi series oscilloscopes.
• MATLAB Runtime Component 7.7 is required to run the MATLAB script for the distortion test
o Available for download from Teledyne LeCroy website
• A pair of SMA cables of equal length. Depending upon the oscilloscope model SMA/BNC
adapters may also be required.
Note: A Teledyne LeCroy ZD1000 Differential Probe or greater can alternatively be used
• AWG for Distortion Test - Teledyne LeCroy WaveStation 2022 or equivalent AWG
• Test Fixture - Teledyne LeCroy recommends the use of the TF-ENET-B (Ethernet test fixture)
with QPHY-BroadR-Reach if an RJ45 connection is available. Equivalent test fixtures may
also be used.
Note: The TF-ENET-B requires a RJ45 input. Due to the variety of different potential
connectors on the UTP (Unshielded Twisted Pair) cable, the operator will be responsible
for providing a method to connect the UTP cable to the RJ45 input on the TF-ENET-B.
Alternatively, a custom SMA breakout fixture can be used. See Physical Setup for more
information.
