5-040-035 Issue 1
Design, materials and specification are subject to change without notice. Superwinch is not responsible for printing errors inadvertently made
in the production of this leaflet. The pictures are for illustrative purposes only and the products and accessories may vary between countries.
Control Box, if supplied, may be
fitted in different location
61612900
61612901
Exxtreme Performance Trophy, 12 volt, winch only.
DESIGNATION : Exxtreme Performance, 12 volt
Voltage: 12 volt (requires 2 batteries)
Recommended Rope: 9.5mm or 11.0mm
Drum dimensions: 63.5mm x 225mm
Maximum Drum capacity: 75m of 9.5mm / 50m of 11.0mm
PERFORMANCE:
Line Speed. 50-56m/min average (Depends on rope dimension)
Line Pull, 1 st layer 55.6kN (5,670kg)
Line Pull, 2 nd layer 43.8kN (4,468kg)
Line Pull, 4 th layer 30.7kN (3,132kg)
Motor Current Draw @ rating 1000 Amps total
Weight, when fitted 63.5kg
ACCESSORIES: Part Number :
Aluminium Hawse 90-24507
Bow Shackle 0509
(UK EU)
2538
(NA)
TM
:
Pulley Block 7755
AKA “The winch without compromise!”
®
Exxtreme Performance Rallye 12 volt winch includes:
Part Number Description:
Exxtreme Performance,12 volt
Superwinch, LLC.
359 Lake Road
Dayville, CT 06241 USA
tel: 1.800.323.2031
fax: 1.860.963.0811
[email protected]
www.superwinch.com
Superwinch, LTD.
Union Mine Road
Pitts Cleave
Tavistock, Devon UK
PL19 ONS
tel: +44 (0) 1822 614101
fax: +44 (0) 1822 615204
[email protected]
www.superwinch.com
®
control box, hand-held remote, hook, hawse, (no rope).
