EA-AMP-12D-45A Installation Manual
Pg. 17
www.snapav.com Support: 866.838.5052
7. Specifications
Continuous Power Output
(All Channels)
45 watts RMS at 4 ohms
30 watts RMS at 8 ohms
Bridged Power Output
(All Channels)
90 Watts per channel RMS at 8 ohms
Note: Maintain 8 ohm minimum when using bridge mode
Input Sensitivity 500mV
Input Impedance 20,000 ohms
AUTO ON (Audio Sense)
Sensitivity
2.5mV
12 Volt Trigger Input 12V DC; 10K Ohms
12 Volt Trigger Output 12V DC; 10mA
S/N ratio 95 dB
Frequency Response 20 Hz to 20 kHz
Distortion (Un-bridged) 0.1% THD 20 Hz-20 kHz
Distortion (Bridged) 0.1% THD 20 Hz-20 kHz
Input Voltage 115V AC/230V AC
Fuse
115V AC T8AL 250V
230V AC T4AL 250V
Dimensions (Inches) 17”W x 2.3”H x 11”D
Weight 9.4 lbs.
Certification Meets FCC Part 15, ETL Listed and tested under UL/EN60065
