ECA-70MIXAMP-1-120 Installation Manual
pg. 12
Specifications
Rated Power Output 120 watts
4 Microphone Inputs XLR balanced with phantom power
Sensitivity -50/-2 dB 2.5/500 MV
Signal To Noise Ratio >68 dB
Frequency Response 40/17.000 hz (-3 dB)
Phantom Power +48 v
Input Sensitivity/Impedance Source 1: 500MV/47 kΩ
Source 2: 200MV/47 kΩ
Source 3: 500MV/47 kΩ
Source 4: 200MV/47 kΩ
Signal To Noise Ratio 90 dB
Frequency Response 40 - 18 kHz (-3 dB)
Control
Bass
± 12 dB
Treble ± 12 dB
Chime 2 and 4 tone options
Output Electro/Impedance 775 MV / 47 kW
Output Rec/Impedance 200 MV / 1 kW
Distortion <0.1%
Operating Condition
AC Mains Input
120V AC, 24V DC (Optional)
Dimensions (D x W x H) 19” x 14.3” x 3.5”
Power Consumption 160 watts
Weight 24 lbs.
