s Door receivers or electric lock
columns – Receivers may be supplied
to capture the front edge of the door.
Lock columns provide a method of
mounting a lock, protecting the wiring
and installing the door receiver.
Electrical Characteristics__
(Indication switch)
Single-pole, double-throw (SPDT),
15 amps @ 125 or 250 VDC.
Dimensional Data_______
Note: Dimensions are for information
and planning purposes only and should
not be used as templates.
Models Available________
FOLGER ADAM LOCKING DEVICES Drive: Manual
Release: Individual
Security
Level:
Maximum
102 TRACK AND
HANGER SETS
NOTE: When a door width falls between two track set sizes, specify the smaller size.
Model Description Door Width Cell Structure Weight (lbs.)
102-1G Track/hanger set 2'-0" – 2'-6" Grille 95
102-1M Track/hanger set 2'-0" – 2'-6" Masonry 95
102-2G Track/hanger set 2'-6" – 3'-0" Grille 110
102-2M Track/hanger set 2'-6" – 3'-0" Masonry 110
102-3G Track/hanger set 3'-0" – 3'-6" Grille 125
102-3M Track/hanger set 3'-0" – 3'-6" Masonry 125
