1
Rx+
Data Receive
Rx+
Data Receive
2
Rx-
Data Receive
Rx-
Data Receive
3
Tx+
DataTransmit
Tx+
Data Transmit
4
-Vdc_return(+)
Feeding power(+)
NC
Not Connected
5
-Vdc_return(+)
Feeding power(+)
NC
Not Connected
6
Tx-
Data Transmit
Tx-
Data Transmit
7
-Vdc
Feeding power(-)
NC
Not Connected
8
-Vdc
Feeding power(-)
NC
Not Connected
