6. LED Description
LED
FX LNK/ACT
FX
FDX/COL
TP LNK/ACT
TP 100
PWR
PoE
1.
Function
Overview
Color
Green
Amber
Green
Green
Green
Green
Lit when fiber connection is good
Blinks when fiber data is present
Lit when full-duplex mode is active
Off when half-duplex is active
Blinks when collision is present
Lit when TP connection is good
Blinks when TP data is present
Lit when TP speed is 100Mbps
Off when TP speed is 10Mbps
Lit when +5V power is coming up
Lit when PoE power is coming up
IEEE802.3u 100Mbps Fast Ethernet supports two types of
media, 10/100Base-TX and 100Base-FX, for network
connection. LFP (Link Fault Pass Through) feature enhances
the TP-Fiber Link integrity and conformity. Either one of TP
or Fiber port is in link-fail state, the LFP converter forces the
other port to be at link-disabled state. Comply with IEEE
802.3af, its advanced auto-sensing algorithm enables taking
power form IEEE 802.3af Power Source Equipment (PSE) or
Power over Ethernet (PoE) injector. It also supports high
safety with short circuit protection and power-in auto-
detection (power from AC/DC power adapter or PSE device).
The power adapter is optional, not included in the standard
package. Please contact your local dealer for purchasing.
7. DC Jack and AC-DC Power Adapter
The DC jack's central post is 2.5mm wide.
DC Jack :
DC Input : 2.5mm
+5V 2A
2. Model Description
Model
FVT-0103TXFC
Power Description
60mA@-48VDC over Cat.5
Wavelength
1310nm
The 100Mbps Fiber Transceiver
SC multi-mode 2Km
Fig. 10 DC+5V Input Jack and Dimension
8. Connecting to TP, Fiber Device
Converter
TP Port
10/100TP
Converter
Fiber Port
100FX
AUTO, FORCE selectable: Bit 1, 2, 3 of S1
a. AUTO: 10/100 NWay Auto-negotiation
b. FORCE: 100 or 10, FDX or HDX
100Mbps duplex selectable: Bit 5 of S1
a. FDX for 100FDX fiber link partner, default
b. HDX for 100HDX fiber link partner
